Interview Questions and Answers

Altair HyperWorks is a comprehensive CAE (Computer-Aided Engineering) simulation platform developed by Altair Engineering. It includes tools for pre-processing (HyperMesh), solving (OptiStruct, RADIOSS, etc.), post-processing (HyperView, HyperGraph), and optimization. It is widely used in industries like automotive, aerospace, and manufacturing for finite element analysis, multi-body dynamics, CFD, and design optimization.

HyperMesh is the pre-processing module of HyperWorks. It is a high-performance finite element pre-processor that allows users to import CAD geometry, clean it up, generate high-quality meshes (1D, 2D, 3D), assign materials/properties, apply loads and boundary conditions, and set up solver decks for various solvers like OptiStruct, RADIOSS, ANSYS, Abaqus, etc.

1D elements (bars, rods, beams, springs), 2D elements (shells/tri/quad), 3D elements (tetra, hexa, penta). Common types: CBEAM, CBAR, CROD for 1D; CTRIA3, CQUAD4 for 2D; CTETRA (4/10 node), CHEXA (8/20 node) for 3D.

Mesh quality refers to how well the finite elements represent the geometry and ensure accurate results. Poor quality leads to inaccurate or failed simulations. Key checks include aspect ratio, skewness, warpage, Jacobian, tet collapse, etc.

Aspect Ratio < 5 (ideally < 3), Warpage < 5°, Skewness < 60°, Jacobian > 0.7, Min/Max Angle (Tri: 20-120°, Quad: 45-135°).

Shell meshing is used for thin-walled structures (mid-surface extraction), faster and sufficient for bending-dominated problems. Solid meshing (tetra/hexa) is for thick/bulk parts where through-thickness stress variation matters.

Use Geometry tab: Defeature (remove small features, holes), Equivalence (merge free edges), Surface edit (fill holes, trim), Topology repair to ensure a watertight manifold geometry.

Mid-surface extracts the middle surface from solid CAD for thin parts (sheet metal, plastics). Used to create shell mesh instead of solid mesh for efficiency in structural analysis.

Tetrameshing generates 3D tetrahedral elements. Tet collapse measures how distorted a tet element is (ideal = 1, poor < 0.2). Control by using finer surface mesh, volume tet parameters, or CFD tetmesh for better quality.

OptiStruct is the structural solver and optimization engine in HyperWorks. It performs linear/nonlinear static, normal modes, buckling, frequency response, and advanced optimizations like topology, topography, shape, and size optimization.

Topology (material distribution), Topography (bead/stamp optimization), Free-size (thickness optimization), Size (gauge optimization), Shape (node perturbation), Free-shape, and combined optimizations.

Linear: Small deformations, linear material, constant BCs. Nonlinear: Large deformations (geometric), material nonlinearity (plasticity), contact, time-dependent loads.

Use Interfaces panel: Create TYPE7 (slide) or TYPE2 (tied) contacts for RADIOSS, or CONTACT card with freeze/track for OptiStruct. Define master/slave surfaces, friction, gap.

Jacobian measures element distortion by comparing actual vs ideal shape. Value ranges 0-1; > 0.7 is generally acceptable (higher is better).

Warpage: How much a quad deviates from planarity (ideal 0°). Skewness: Angle deviation from 90° at corners (ideal 0°).

1D: Line elements (beams, rigs). 2D: Surface mesh (shells). 3D: Volume mesh (solids). Chosen based on part thickness and analysis type.

Use Quality Index panel or Check Elems (2D/3D tab). Failures shown in red. Improve by remeshing, node movement, split/combine elements, adjust parameters.

RBE2: Rigid link (infinite stiffness, dependent nodes follow independent exactly). RBE3: Interpolating element (distributes load/weight based on DOFs, no added stiffness).

To find the optimal material layout within a design space for given loads/BCs, minimizing weight while meeting stress/displacement constraints.

Go to File > Export > Solver Deck, select solver (OptiStruct, Nastran, etc.), choose template, and export .fem or .bdf file.
