OrCAD is an Electronic Design Automation (EDA) software suite used for schematic capture, PCB layout, simulation, and electrical design verification.

Key modules include OrCAD Capture, OrCAD PCB Designer, OrCAD PSpice Simulator, OrCAD Library Builder, and OrCAD CIS.

OrCAD Capture is the schematic entry tool used for creating and editing electronic circuit diagrams.

OrCAD PSpice is a simulation tool that allows analog, digital, and mixed-signal circuit analysis.

OrCAD PCB Designer is used for PCB layout creation, routing, layer management, and manufacturing output generation.

A netlist is a file that defines components and electrical connections between schematic symbols for PCB layout.

DRC verifies layout compliance with electrical and manufacturing rules such as spacing, trace width, and drill sizes.

ERC checks schematic-level electrical issues like unconnected pins, wrong pin types, and signal conflicts.

Footprints represent the physical land pattern of components on the PCB used for placement and routing.

Custom symbols are created using the symbol editor by defining pins, shapes, attributes, and component properties.

Differential pairs are two traces carrying complementary signals; OrCAD maintains matched impedance and length.

The constraint manager defines electrical rules such as spacing, net classes, impedance, and timing constraints.

Schematics created in OrCAD Capture can be simulated directly using PSpice models for validation.

Back-annotation updates schematic data based on changes made in PCB layout, such as component renaming.

Forward annotation sends changes from the schematic to PCB layout, ensuring synchronization.

OrCAD generates Gerber files, drill files, netlists, IPC-2581, ODB++, and assembly drawings.

Copper pour fills PCB regions with grounded or power-plane copper for improved current handling and EMI reduction.

OrCAD CIS (Component Information System) manages component libraries and links them to company databases.

OrCAD allows defining multiple board layers, stack-up properties, impedance control, and routing constraints.

Variant design allows creating different PCB assembly versions using the same schematic but different components.
