Interview Questions and Answers

Tool design engineers collaborate closely with manufacturing and quality control to ensure that tools are designed for manufacturability, meet quality standards, and are properly maintained.

A jig guides the cutting tool, while a fixture holds the workpiece in a fixed position during machining or assembly.

Ethical considerations include ensuring the safety of operators, designing tools that minimize waste, and complying with environmental regulations.

Key considerations include gate location, runner design, cooling channels, venting, ejection system, and material shrinkage.

By performing thermal analysis to identify hot spots and designing cooling channels to maintain a uniform temperature distribution throughout the mold.

Challenges include meeting tight tolerances, minimizing tool wear, optimizing tool life, reducing costs, and accommodating design changes.

By attending industry conferences, reading technical publications, taking continuing education courses, and networking with other professionals.

FEA is a computer-based simulation technique used to analyze the structural integrity and performance of tools under various loading conditions. It helps identify potential weaknesses and optimize the design.

Cutting forces depend on the material being machined, the cutting tool geometry, the cutting speed, the feed rate, and the depth of cut. Empirical formulas and software tools can be used to estimate these forces.

By designing tools that reduce cycle times, improve accuracy, minimize waste, and automate processes.

Ergonomics is important for ensuring that tools are comfortable and safe to use, reducing the risk of repetitive strain injuries and improving operator productivity.

Consider the complexity of the tool, the required tolerances, the material properties, the production volume, and the cost of manufacturing.

GD&T (Geometric Dimensioning and Tolerancing) is a symbolic language used to define and communicate manufacturing tolerances. Its crucial for ensuring proper fit, function, and interchangeability of parts.

The process typically involves understanding the manufacturing requirements, creating preliminary designs, performing simulations and analysis, selecting materials, detailing the design, and overseeing the fabrication and testing of the tool.

By performing thorough simulations and analysis (e.g., FEA), considering tolerances, using appropriate materials, and conducting rigorous testing and inspection.

Tool design engineers design a wide variety of tools, including cutting tools, forming dies, injection molds, jigs, fixtures, gauges, and automated assembly equipment.

Common materials include tool steels (e.g., high-speed steel, carbide), alloy steels, cast iron, aluminum, and polymers, depending on the application and performance requirements.

A tool design engineer designs and develops tools, dies, molds, jigs, fixtures, and other specialized equipment used in manufacturing processes.

Essential skills include proficiency in CAD software (e.g., AutoCAD, SolidWorks, CATIA), knowledge of manufacturing processes (e.g., machining, casting, molding), materials science, GD&T, and problem-solving abilities.

Common software includes AutoCAD, SolidWorks, CATIA, NX (Siemens), Creo Parametric, and specialized CAM software for generating toolpaths.

Problem definition, Design exploration, Design optimization, and Design communication.

The five types of loads that can act on a structure are tension, compression, shear, bending and torsion.

Endurance limit is affected by many factors such as surface finish, reliability, temperature, size etc.

Explain with examples that sync with the job description.

Ductility:- Ductility is the ability of a material to be drawn or plastically deformed without fracture. the ability of a material to have its shape changed (as by being drawn out into wire or thread) without losing strength or breaking.

fatigue:- Material fatigue is a phenomenon where structures fail when subjected to a cyclic load. Fatigue is the most common source behind failures of mechanical structures.

Machinability:- Machinability is the ease with which a metal can be cut (machined) permitting the removal of the material with a satisfactory finish at low cost. Materials with good machinability (free machining materials) require little power to cut, can be cut quickly, easily obtain a good finish, and do not wear the tooling much.

S-N Curve:- A SN-Curve (sometimes written S-N Curve) is a plot of the magnitude of an alternating stress versus the number of cycles to failure for a given material.

Curved Beam:- Beam having its neutral axis curved in unloaded condition is known as curved beam. Neutral axis and centroidal axis of a curved beam do not coincide. Neutral axis of curved beams is shifted towards the centre of curvature.25

Goodman & Soderberg diagrams:- Within the branch of materials science known as material failure theory, the Goodman relation (also called a Goodman diagram, a Goodman-Haigh diagram, a Haigh diagram or a Haigh-Soderberg diagram) is an equation used to quantify the interaction of mean and alternating stresses on the fatigue life of a material.

Factor of safety:- A factor of safety is the load carrying capacity of a system beyond what the system actually supports.

Endurance limit:- It is defined as maximum value of the completely reversed bending stress which a polished standard specimen can withstand without failure, for infinite number of cycles (usually 107 cycles).

Impact Load:- Machine members are sometimes subjected to abrupt loads as a result of falling or colliding with another object. The impact load is the force created as a result of these actions. The Impact stress is the stress created in the machine members as a result of the impact load.

Repeated stress is stress varying from zero to a maximum value of same nature. Reversed stress of cyclic stress varies from one value of tension to the same value of compression.

Answer appropriately.

The rotating beam specimen is small with X mm diameter. Now if the size of the standard specimen is increased, then the endurance limit of the material will decrease.

Self-weight of the machine.

Energy Transmitted.

Change of temperature.

Frictional resistance.

The inertia of reciprocating parts.

Unbalance of Moving parts.

Computer-aided design (CAD) is one of the most ubiquitous software design tools.

The growth of a crack, the extension of the surfaces on either side of the crack, requires an increase in the surface energy. Griffith found an expression for the constant. in terms of the surface energy of the crack by solving the elasticity problem of a finite crack in an elastic plate.
